30khz Durable Ultrasonic Cutting Device for Honeycomb materials

30khz Durable Ultrasonic Cutting Device for Honeycomb materials

Ultrasonic cutting machine is used for cutting rubber, synthetic fabric, cloth, plastic, sheet metal, food etc. The cutting of products using ultrasound is performed when an ultrasonic blade comes into contact with the product to be cut, the high vibration of 30,000 pulses per second, makes this product very easily be cut even if it is of delicate or sticky texture composition. The much higher vibration does not allow any product to stick to the blade. The cut is clean and without pressure on the product.

Honeycomb materials and structures are increasingly used in the aeronautics industry. Machining these materials using traditional methods is often complex, costly, and unsatisfactory in terms of quality and accuracy.
CRENO has developed a unique solution, qualified by aerospace, for these materials by combining the advantages of the ultrasonic cutting process and traditional milling machines.

Parameter

Advantages

1.The cutter head is made of imported high-hard alloy steel with high hardness and long service life;
2.The blade is sharp, compact, and can be cut quickly;
3.Suitable for any occasion, safe, not hurting people, easy to operate;
4.Suitable for cutting all kinds of non-woven fabrics, can cut any shape;
5.Cutting without burrs, the cut is neat and beautiful.

Application:

Ultrasonic cutting equipment is suitable for cutting:

1. Thermoplastics (plates, sheets, films, laminates)
2. Carbon fiber CFRP
3. Rubber (vulcanized latex, non-vulcanized latex, film material, tube)
4. Composites (prepregs, polyethylene fibers, carbon molded products or glass fibers (GFRP))
5. Resin
6. Silicone
7. food
8. foam
9. Paper (honeycomb)
10. PVC foam board
