Premium 35Khz Ultrasonic Spot Welding Machine - RPS-SONIC

Premium 35Khz Ultrasonic Spot Welding Machine - RPS-SONIC

short description:

Short description:

Pistol ultrasonic spot welding machine, also known as portable ultrasonic welding machine, hand-held ultrasonic welding machine, hand-held welding machine, portable welding machine, ultrasonic spot welding machine, riveting machine, ultrasonic spot welding machine, can be used for butt welding of thermoplastics , Can also replace the welding head according to customer needs, used for riveting, spot welding, embedding, cutting and other processing techniques. Compared with other traditional processes (such as gluing, electric ironing or screw fastening, etc.), it has high production efficiency and welding Notable advantages such as good quality, environmental protection and energy saving.


  • Frequency: 35Khz
  • Power: 600w
  • Horn material: Titanium
  • Horn size: Customized
  • Weight: 15kg
  • Generator type: Digital
  • Name: ultrasonic spot welding machine

Product Detail
FAQ
Product Tags
In the fast-evolving world of manufacturing and assembly, the demand for reliable, efficient, and versatile welding solutions has never been higher. RPS-SONIC stands at the forefront of this technology with our cutting-edge 35Khz Ultrasonic Spot Welding Machine. Designed with meticulous attention to detail and engineered for the desktop, this innovative machine sets a new standard in ultrasonic welding. At the heart of our Ultrasonic Spot Welding Machine lies a powerful 28Khz hand welder, optimized for performance and user-friendliness. With a robust 800W output powered through a state-of-the-art digital generator, this machine delivers unparalleled welding accuracy and strength. Its versatility is evident in its wide range of applications, from automotive to consumer electronics, and notably, for PP box welding, highlighting its capability to handle a variety of materials with precision.

Desktop 35Khz ultrasonic spot welding machine for ultrasonic welding



Parameter

Item Parameter Advantage: Application
28Khz ultrasonic hand welder

Straight type

 ▪ 28Khz 800W

▪ Digital generator

▪ Horn customized

▪ Aluminum alloy&Steel & Titanium alloy

▪ Power Supply: 220v 50/60HZ

 1. light generator ,light hand welder.The generator 120*120*380, whole weight5KG, with generator 4kg, and the 28Khz hand welder 1kg, 35Khz hand welder 0.8kg. Suit for hand operate.

2. Special alloy metal housing, the housing of the hand-welder is light but firm, not easy to be deformed, longer it’d using life.

3. Digital generator, it can tracking the frequency itself, easy for operate. Output /welding time adjustable, suit for both hand operate and machine operate.

 PP PVC Fabric woven PE ABS

PS Nylon PU PET All Thermoplastic material, the thickness 8mm in max.



Straight type suit for both hand /machine operate.

Gun type suit for hand operate.




28Khz ultrasonic hand welder

Gun type
35Khz ultrasonic hand welder

Straight type

 ▪ 35Khz 500W

▪ Digital generator

▪ Horn customized

▪ Aluminum alloy&Steel & Titanium alloy

▪ Power Supply: 220v 50/60HZ

 PP PVC Fabric woven PE ABS

PS Nylon PU PET All Thermoplastic material, the thickness 5mm in max.



Straight type suit for both hand /machine operate.

Gun type suit for hand operate.


35Khz ultrasonic hand welder

Gun type
For better application , it is better share all the material information with me, the material, thickness, operate way, speed requirements before order .

We also supply 20Khz 40Khz ultrasonic hand-weld welder.



Description



Ultrasonic spot welding machine can be used for butt welding of thermoplastic, can also be replaced according to customer needs welding head, for welding, spot welding, embedded, cutting and other processing technology, compared to other traditional processes (such as adhesive, Fastening, etc.), with high production efficiency, welding quality, environmental protection and energy saving and other significant advantages. Through the welding of ultrasonic energy to the welding area, due to the welding of the two joints at the interface of large resistance at the interface, it will produce local high temperature. And because of poor thermal conductivity of plastic, the moment can not be distributed in time, gathered in the welding area, resulting in two plastic contact surface rapid melting, coupled with a certain pressure, to integrate into one. When the ultrasonic stops, let the pressure last for a few seconds to make it solidified, thus forming a solid molecular chain, to achieve the purpose of welding, welding strength can be close to the strength of raw materials.



Ultrasonic Spot Welder Application

Portable spot welding machine is widely used in the apparel industry, the trademark industry, the automotive industry, plastic electronics, household goods industry.
Clothing industry: underwear pants needle before the process, the ribbon elastic belt welding; can be used for point drilling.
Trademark industry: weaving Mark with, India-Mark, and so on.
Automotive industry: door noise cotton, wiper seat, engine cover, water tank cover and so on.
Plastic electronic: small plastic pieces riveting and so on.
Household goods industry: fiber cotton spot welding and so on.

Advantages of portable ultrasonic welding machine

Hand-held ultrasonic welding is a fast, clean, safe and other advantages of plastic parts to achieve the advanced technology, the use of Japanese components, force large-scale reliable; multiple protection circuit for enterprises to provide efficient welding methods to reduce production costs.



Understanding the diverse needs of the industry, we've ensured that our ultrasonic spot welder comes equipped with a horn that can be customized to your specific requirements. Whether you're dealing with aluminum alloy, steel, or titanium alloy, this machine adapts seamlessly, ensuring a perfect weld every time. Furthermore, it's designed to cater to a global audience, operating efficiently on a 220v 50/60HZ power supply. This machine is not just about power and versatility; it's also about providing a user-friendly experience. The ergonomic design of the 28Khz ultrasonic hand welder ensures comfort and ease of use, making it an ideal choice for extended welding sessions. Whether you're a seasoned professional or new to the field of ultrasonic welding, the RPS-SONIC 35Khz Ultrasonic Spot Welding Machine is engineered to elevate your welding projects to new heights of efficiency and quality.
  • Previous:
  • Next:

    • Q1.What kind material of the horn?

    A. Titanium alloy, we also customized aluminum hom for customer before.

    Q2.What’s the time of delivery?

    A. For Conventional hom, 3 days, for customized hom 7 work days.

    Q3.Does ultrasonic extraction also require the addition of a chemical catalyst?

    A. No . but some time need Mechanical stiring.

    Q4.Can the device work continously?

    A. Yes ,it can work 24hours continously.

    Q5.What’s the Processing capacity of one set ultrasonic extraction equipment?

    A. Different hor different Processing capacity, for 2000W Nine section whip horm can dealing 2L~10Lmin.

    Q6.What’s the warranty of your sonicator equipment?

    A. All equipment one year warranty.
