Ultrasonic Candy Cutting: Reshaping a New Paradigm of Efficiency and Precision in the Candy Processing Industry

Ultrasonic Candy Cutting: Reshaping a New Paradigm of Efficiency and Precision in the Candy Processing Industry

short description:

Ultrasonic candy cutting technology does not rely on the "hard extrusion" of traditional mechanical cutting, but uses the energy of ultrasonic vibration to achieve precise separation of materials.
Product Detail
FAQ
Product Tags
Parameter

Machine Ultrasonic rubber/cake Cutter
Frequency(KHz) 20Khz
Power 1000 W
Cutting Blade / Horn Titanium
Voltage(V) 220V
The width of blade depend on your requirement
Cutting thickness 10~20mm(depend on materials)
Horn amplitude 10-40μm
Equipment weight 2t




An ultrasonic generator converts mains power into high-frequency electrical energy, which is then converted into mechanical vibration by a piezoelectric converter. The amplitude is amplified by an amplitude transformer and transmitted to the titanium alloy cutting blade. The blade vibrates at high frequency to produce a near-frictionless cutting surface, thus enabling the cutting of food.

Product Features:

1. Excellent Cutting Effect: Smooth and neat cut surface, no sticking, no deformation due to compression, and no debris or burrs. For multi-layered products, it maintains the color and layers of the cut surface.

2. Wide Applicability: Can cut various types of food, including frozen products, cream products, and high-viscosity foods such as cakes, bread, cheese, butter, candy, and meat.

3. High Efficiency: Fast cutting speed; for example, the UFM2100 model can cut up to 150 times per minute, processing 150-600 products per hour.

4. Hygiene and Safety: Parts in contact with food are made of silicone and food-grade plastic, meeting hygiene standards. Ultrasonic cutting reduces friction between the blade and food, minimizing blade wear and the risk of impurities contaminating the food.

5. Low Maintenance Costs: Due to low friction, the blades experience almost no wear, eliminating the need for frequent blade replacements and reducing downtime for blade cleaning, thus lowering maintenance costs.
